8 Shuttle Circular Loom
SM-8/2200
8 Shuttle Circular Loom
SPECIFICATION MODLE SM 8/2200
Working Ability Shuttle Speed RPM 30 -70
Nos. Of Shuttle Set 8
Weft Inserting Speed RPM 240 - 560
Weft Density P / Inch 8 - 16
Lay Flat Width MM 1800 - 2200
Weft Package Size Weft Tube MM ID (23 - 28) ψ
Maximum Weft Package MM ψ100
Warp Tube MM ID (23 - 28) ψ
Warp Creel Bobbin 2560
Cloth Winder Maximum Winder
Roller Width
MM 2400 Standard
Extra 4600
Take Up Driving   Gear Transmission
Torque Motor KG 15 KG-CM
Power Main Motor 3P KW 11 KW (15 HP × 8P)
15 HP Inverter
Fan Motor 3P KW 1 HP
Layout & Packing Dimension L × W × H M 14.1 × 5.2 × 5.6
Packing G.W. MT 7.2
Specifications are subject to change for improvement without notice.
Optional device available upon request:
1. SM 8/2200 Extra winder for 4600 width with center open device.
                    Extra winder for 2400 width with side edge open device.
2. Gusset device.
8 shuttle circular loom good for big bag, Tarpaulin cloth, geotextile, Agriculture cover fabric

SM8-2200 is used for producing heavy duty container bags / Geotextile / tarpaulin / agriculture cover fabric, etc.
Light fabaric as tubular flat width upto 220 cm (8 feet) and open it for 4400 mm width for agriculture cover fabric.

Main driving motor equipped with Inverter for easy adjusting producing speed and saving power.
