Multi-wall PP PE-Paper Bag Making Machine
26M-P
Multi-wall PP PE-Paper Bag Making Machine
DRIVING MOTOR DATA
Main Motor 20 HP (with inverter)
EPC Driving Motor 1/2 HP × 1Set
Printing Driving Motor 1/2 HP × 1/8 HP (color)
Pump of Cross Pasting Unit 1/2 HP
Pump of Paper Pasting Unit 1/2 HP
Driving Motor of Conveyer 1 HP
Extruder Main Motor 7 1/2 HP (with inverter)
Heating Capacity 9.85 kw

This machine includes nine (9) units, by which form into a complete set of machinery for integral operation.

The complete and continuous processing cycle starts with single PP /PE laminated cloth or sandwich PP / Paper laminated cloth printing - joining - pasting  perforating - forming - rotary cutting - conveying counting. It's capable of producing cement, fertilizer, sugar, flour and chemical product packing bags.

OPTIONAL DEVICE:
1. ROLL STAND WITH  E. P. C.
2. PRINTING UNITS
3. ROLL STANDS
4. CROSS PASTING UNIT (OPTIONAL)
5. PAPER PASTING UNIT
6. FORMING UNIT
7. ROTARY CUTTING UNIT
8. CONVEYER
9. EXTRUDER
